Waterproof EcoMax G4

LEDWaterproof-E4 L06-18W-DALI-840

Product Code
531000043300
  • Waterproof luminaire in "sealed-for-life" concept
  • Quick & easy installation due to twist-and-lock endcap
  • Standard equiped with Power switch
  • Supplied with vandal-proof stainless steel ceiling and suspension clips
  • Equipped with 3x2.5mm² throughwiring

Specifications

Electrical data

Nominal voltage 220|240 V
Voltage type AC/DC
Max. system power 18 W
Max. number of luminaires per miniature circuit breaker B16 (MCB) 26
Max. number of luminaires per miniature circuit breaker C16 (MCB) 65
Power factor 0.95
Surge protection 2 kV
With sensor No
Max. inrush current 19.6 A
Inrush time 236
Max. number of luminaires per miniature circuit breaker C10 (MCB) 40
Max. number of luminaires per miniature circuit breaker C13 (MCB) 52
Including emergency lighting No
Nominal voltage DC 180|260 V
Frequency 50|60 Hz

Photometrical data

Colour temperature 4000 K
Equivalent to TL 1x18W
Colour consistency (SDCM) 4
Colour rendering index (CRI) > 80

Light technical data

Beam angle 120°
Beam angle 120°

Lifespan

Lifetime (L70) 100000 h
Lifetime (L80) 100000 h
On-/Off-cycles 100000
Lifetime (L90) 50000 h

Capabilities

Dimmability DALI2
With sensor No

Certificates and standards

Protection class according to IEC 61140 II
Impact strength IK08
Glow wire test 850°C
Risk group (EN 62471) RG0
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 1%
Input current 0.091 A
Wirethrough No
Housing colour Grey
Finishing Grey RAL 7035
Cover material Polycarbonate
Pressure valve No
Coastal proof No
Length 680 mm
Width 63 mm
Height/depth 62 mm
Application temperature 25°C
Storage environment -30|60°C
Operating temperature -30|45°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
693720960974894051190CT10.066 x 0.066 x 0.767 m0.7 KG

Accessoires



Accessory Trunking - DALI power supply

Product Code
542098001000
In line power supply
